80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame

80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame

  • 80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame
  • 80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame
  • 80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame
80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame
Product Details:
Place of Origin: Guangdong, China
Brand Name: Yunyi Acoustic
Certification: ISO9001
Model Number: SN80
Payment & Shipping Terms:
Minimum Order Quantity: 20 Square Meters
Price: US$52.60 Per Square Meter
Packaging Details: Exporting Carton
Delivery Time: 12-18 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Square Meters Per Month
Contact Now
Detailed Product Description
Product: Office Partitions Dimension: From Site Measurement
Advantage: Easy Installation Application: Apartment
Type: Glass Partition Wall Makings: Glass + Aluminum
Highlight:

80mm Conference Room Glass Walls

,

80mm Glass Partition With Aluminium Frame

,

Glass Partition With Aluminium Frame

High Quality Office Building Glass Partition With Aluminum Frame





Product Description



Office glass partition is a kind of non-load-bearing partition wall, which is composed of tempered glass, titanium magnesium alloy and aluminum louvered in the middle.
Single Glazed Glass Partitions are a great way to enhance your office. By separating work areas and still allowing natural light to pass from room to room, glass partitions will give a spacious feel to your work environment.
Partition Framework – Slim, minimal appearance to the head and base track (25mm). Standard colours are silver (RAL 9006) or black (RAL 9004). Other colours are available on request.
Glass – Clear, toughened (non-fire rated) safety glass with acoustic noise reduction of up to 33dB. Glass thickness is 10mm (max height 2700mm) or 12mm (max height 3000mm).
Single Glazed Glass doors provides the smallest seamless effect. The default width is 900 mm. You can choose sliding doors, swing doors and floor spring doors.​



Model SN40 SN80-1 SN80-2 SN103

Model

Description

Sono 40 series with single layer glass Sono 80 series with single layer glass Sono 80 series with double layer glass Sono 103 series with double layer glass
Structure Thickness 40mm 80mm 80mm 103mm
Glass Thickness 8/10mm 10/12mm 5/6mm 5/6mm
Frame Color Anodized, power coated, painted with wood grain
Glass Color Clear glass, tinted glass, laminated glass, frosted glass, photochromic glass
Louver Option Not available Not available Manual or electric



The size, color and finishes. We can produce the partitions wall based on the difference demands of different client. The price is difference based on the different size and material, Welcome to contact us for more details.

80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame 0





Product Superiority



1. Discreet horizontal and slimline vertical profiles maximise the glazing at the element joints, available in anodised aluminium or with coloured options.
2. The unique frame profile allows glass elements to be combined with solid elements in a variety of panel finishes including laminate, fabric and veneer for a truly integrated appearance.
3. The system allows a choice of integral pass doors, including solid single and double doors and the ultra-transparent glass door and over panel.
4. Enhancements can include automated integrated blinds or switchable 'Magic Glass' for instant privacy.
5. This product can be fully customised with manifestations, or a range of finishes including screen printing, coloured writeable glass and logo placement. In addition, glazing bars can be applied to give a modern look.

80mm Conference Room Glass Walls , Glass Partition With Aluminium Frame 1
