| Place of Origin: | Guangdong, China |
| Brand Name: | Yunyi Acoustic |
| Certification: | SGS |
| Model Number: | SN80 |
| Minimum Order Quantity: | 20 Square Meters |
|---|---|
| Price: | US$52.60 Per Square Meter |
| Packaging Details: | Exporting Carton |
| Delivery Time: | 12-18 Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Square Meters Per Month |
| Features: | Sturdy & Durable | Materials: | Double Layer Glass With Blind Inside |
|---|---|---|---|
| Size: | Custom Made | Style: | Office Glass Partition |
| General Use: | Office | Frame: | Aluminum Profile |
| Highlight: | ODM Office Glass Partition Walls,Double Layer Glass Office Dividers,SN80 Office Glass Partition Walls |
||
Office Glass Partition Tempered Office Glass Partition Glass Partition Wall
Product Description
Double Glazed Glass Partitions are a great way to enhance your office. By separating work areas and still allowing natural light to pass from room to room; glass partitions will give a spacious feel to your work environment.
Partition Framework – Slim minimal appearance floor and ceiling tracks to take two layers of glass. Standard colours are silver (RAL 9006) or black (RAL 9004). Other colours are available on request.
Glass – We are able to offer higher performance glass options to achieve 43dB sound insulation, using 5mm and 8mm toughened glass. For higher acoustic performing systems please contact us.
Double Glazed Glass doors provides the best sound isolation. The default width is 900 mm. You can choose sliding doors, swing doors and floor spring doors.
| Model | SN40 | SN80-1 | SN80-2 | SN103 |
|
Model Description |
Sono 40 series with single layer glass | Sono 80 series with single layer glass | Sono 80 series with double layer glass | Sono 103 series with double layer glass |
| Structure Thickness | 40mm | 80mm | 80mm | 103mm |
| Glass Thickness | 8/10mm | 10/12mm | 5/6mm | 5/6mm |
| Frame Color | Anodized, power coated, painted with wood grain | |||
| Glass Color | Clear glass, tinted glass, laminated glass, frosted glass, photochromic glass | |||
| Louver Option | Not available | Not available | Manual or electric | |
Product Design
1.Design
We design profiles and systems that are easy to install, highly soundproof and fire resistant for our modular partition wall and door systems, which are owned by all designs and patents.
2. Project
We identify the materials that should be used according to details of project and start working on your projects accordingly.
3. Manufacturing
We use computer-controlled machines to produce materials to keep the error within a very small range.
4. Delivery
We safely realize domestic and international shipment of materials we produce, with the right packaging and transportation methods.
5. Assembly
We complete our projects by assembling our modular partition wall and door systems in high quality and as soon as possible.
Advantage
Interior Glass Wall Systems bring the benefits of glass to the workplace - transparency, daylighting, versatility, efficiency, space saving, and low cost of ownership. The wall systems come in a range of sleek but rugged minimalist designs and configurations so you can select the system that best matches your project's functional and aesthetic requirements.
Sono Partition system combined with features to enhance privacy and security. With an innovative blend of metal and glass, the design fully frames the glass panels - adding rigidity and greater sound protection without interrupting sightlines.
Contact Person: Ling Xu
Tel: 86-19860838485
